- チップセット : Intel Z890 Chipset
- 対応CPU : Intel Core Ultra Processors (Series 2) , LGA1851
- フォームファクター : ATX ( 30.5 cm x 24.4 cm )
- メモリソケット …
・4 x DIMM slots, max. 192GB, DDR5
*Support up to 9066+MT/s (OC), Non-ECC, Un-buffered and Clocked Unbuffered DIMM (CUDIMM) Dual channel memory architecture - 拡張スロット …
・2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes)
・1 x PCIe 4.0 x16 slot (supports x4 mode) - インターフェース(バックパネル) …
・2 x Thunderbolt 5 USB Type-C port
・1 x Thunderbolt 4 USB Type-C port
・6 x USB 10Gbps ports (6 x Type-A)
・1 x USB 2.0 port (1 x Type-A)
・1 x DisplayPort (Input only)
・1 x HDMI port
・1 x Wi-Fi module1 x Marvell AQtion 10Gb Ethernet port
・1 x Intel 2.5Gb Ethernet port
・2 x Gold-plated audio jack
・1 x BIOS FlashBack button - 無線機能 …
・2x2 Wi-Fi 7 (802.11be)
*Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate
・Bluetooth v5.4 - ストレージ …
・M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
・M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
・M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
・M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 modes)
・M.2_5 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
・4 x SATA 6Gb/s ports - 対応RAID …
・RAID 0/1/5/10, SATA RAID 0/1/5/10
・M.2 slot from CPU only supports RAID 0/1/5 - 主な付属品 …
Cables
・2 x SATA 6Gb/s ケーブル
Miscellaneous
・1 x ASUS WiFi Q-Antenna
・1 x Q-connector
・2 x M.2 Q-Latch packages
・2 x M.2 rubber packages
・1 x ProArt accessory bag
Documentation
・1 x ACC Express activation key card
・1 x Quick start guide
※仕様及び外観は改良のため予告なく変更される場合がありますので、最新情報はメーカーページ等にてご確認ください。
